Automatic Plastic Waste and Sand Paver Block Hydraulic Press
The plastic-sand paving brick hydraulic press is a specialized three-beam, four-column hot-press molding machine. It primarily uses recycled plastic (PE/PP), sand, and additives as raw materials to mo
+86 13562463338
+86 13562463338
Video Display
Product Introduction
The plastic-sand paving brick hydraulic press is a specialized three-beam, four-column hot-press molding machine. It primarily uses recycled plastic (PE/PP), sand, and additives as raw materials to mold eco-friendly paving bricks, road bricks, and slope protection bricks under high temperature and pressure.Main Structure
Three-beam, four-column frame: Constructed from thick steel plate welded together and aged-treated for high rigidity and resistance to off-center loads, ensuring no deformation even during long-term operation.
Main Cylinder System: Single-cylinder or double-cylinder options available, ensuring stable pressure, smooth downward movement, and sustained pressure retention.
Core Advantages
Eco-friendly Recycling: Utilizes solid waste such as waste plastic and sand to turn waste into valuable resources, aligning with environmental policies.
Low Cost: Low raw material costs, simple process, low energy consumption, and high cost-effectiveness.
Superior Performance: Pavers feature high density, high strength, wear resistance, slip resistance, waterproofing, corrosion resistance, and a long service life.
Multi-Functional: By changing molds, the machine can produce paving bricks, slope protection bricks, tree pit bricks, colored bricks, and more.
Applications
Raw Materials: Recycled PE/PP plastic, sand, stone powder, fiberglass, pigments, etc.
Products: Residential walkway bricks, plaza bricks, parking lot bricks, slope protection bricks, tree pit bricks, and landscape bricks.
Industries: Eco-friendly building materials, recycled resources, municipal engineering, and landscape architecture.
Technical Parameters| Parameter | Unit | YQ32-63 | YQ32-100A | YQ32-100B | YQ32-200A | YQ32-200B | YQ32-315A | YQ32-315B |
|---|---|---|---|---|---|---|---|---|
| Nominal Force | kN | 630 | 1000 | 1000 | 2000 | 2000 | 3150 | 3150 |
| Maximum System Working Pressure | MPa | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
| Maximum Open Height of Slider | mm | 700 | 800 | 900 | 1100 | 900 | 1250 | 1000 |
| Maximum Stroke of Slider | mm | 400 | 500 | 600 | 500 | 600 | 800 | 600 |
| Effective Area of Workbench | mm | 610×500 | 630×550 | 750×700 | 1000×1000 | 800×800 | 1260×1160 | 800×800 |
| Slider Free Fall Speed | mm/s | 100 | 100 | 100 | 100 | 100 | 100 | 100 |
| Pressing Speed | mm/s | 11-22 | 7-15 | 7-15 | 7-18 | 7-18 | 7-12 | 7-12 |
| Return Speed | mm/s | 80 | 90 | 90 | 90 | 90 | 100 | 90 |
| Ejecting Force | kN | 100 | 200 | 200 | 400 | 400 | 630 | 630 |
| Maximum Ejecting Stroke | mm | 160 | 200 | 200 | 200 | 200 | 300 | 300 |
| Name | Unit | YQ32-400 | YQ32-500 | YQ32-630 | YQ32-800 | YQ32-1000 | YQ32-1250 | YQ32-1600 |
|---|---|---|---|---|---|---|---|---|
| Nominal Force | kN | 4000 | 5000 | 6300 | 8000 | 10000 | 12500 | 16000 |
| Maximum System Working Pressure | MPa | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
| Maximum Open Height of Slider | mm | 1250 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| Maximum Stroke of Slider | mm | 800 | 900 | 900 | 900 | 900 | 900 | 900 |
| Effective Area of Workbench | mm | 1250×1160 | 1400×1400 | 1500×1500 | 1600×1600 | 1600×1600 | 1600×1600 | 1600×1600 |
| Slider Free Fall Speed | mm/s | 100 | 100 | 150 | 100 | 180 | 180 | 190 |
| Pressing Speed | mm/s | 5-11 | 10-18 | 9-18 | 7-18 | 10-18 | 6-15 | 6-14 |
| Return Speed | mm/s | 100 | 180 | 200 | 90 | 220 | 200 | 220 |
| Ejecting Force | kN | 630 | 1000 | 1000 | 400 | 1000 | 1000 | 1600 |
| Maximum Ejecting Stroke | mm | 300 | 300 | 300 | 200 | 300 | 300 | 300 |
Pressing process
Customer Case
