Plastic Trash Can Molding Hydraulic Press Machine for Large Capacity Waste Bin Production
The Plastic Garbage Bin Molding Hydraulic Press Machine is a professional hydraulic forming equipment specially designed for the production of plastic waste bins, garbage containers, recycling bins, a
+86 13562463338
+86 13562463338
Video Display
Product Introduction
The Plastic Garbage Bin Molding Hydraulic Press Machine is a professional hydraulic
forming equipment specially designed for the production of plastic waste bins,
garbage containers, recycling bins, and other large-scale plastic products. It adopts
advanced hydraulic control technology and precision molding systems to provide
stable pressure, accurate control, and high production efficiency.
This hydraulic press is widely used for compression molding of HDPE, PP, and
composite plastic materials. Through high-pressure and high-temperature molding
processes, plastic sheets or raw materials can be formed into different sizes and
shapes of garbage bins with excellent strength, smooth surface finish, and consistent
quality.
The machine features a strong welded steel frame structure, high rigidity, and
excellent resistance to deformation during long-term operation. The hydraulic
system provides powerful pressing force and stable performance, ensuring uniform
pressure distribution throughout the molding process. Equipped with PLC control
and touch screen operation, the machine allows operators to easily set parameters
such as pressure, holding time, and molding cycle.
The plastic garbage bin hydraulic press can be customized according to different
customer requirements, including different tonnage capacities, working table sizes,
heating systems, automatic feeding systems, and mold designs. It is suitable for
producing outdoor garbage bins, municipal waste containers, industrial recycling bins,
and environmental protection products.
With advantages of high efficiency, energy saving, easy operation, and long service life,
this hydraulic press machine has been exported to many countries and is an ideal
solution for manufacturers looking to improve production capacity and product
quality.
Technical Parameters
| Parameter | Unit | YQ32-63 | YQ32-100A | YQ32-100B | YQ32-200A | YQ32-200B | YQ32-315A | YQ32-315B |
|---|---|---|---|---|---|---|---|---|
| Nominal Force | kN | 630 | 1000 | 1000 | 2000 | 2000 | 3150 | 3150 |
| Maximum System Working Pressure | MPa | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
| Maximum Open Height of Slider | mm | 700 | 800 | 900 | 1100 | 900 | 1250 | 1000 |
| Maximum Stroke of Slider | mm | 400 | 500 | 600 | 500 | 600 | 800 | 600 |
| Effective Area of Workbench | mm | 610×500 | 630×550 | 750×700 | 1000×1000 | 800×800 | 1260×1160 | 800×800 |
| Slider Free Fall Speed | mm/s | 100 | 100 | 100 | 100 | 100 | 100 | 100 |
| Pressing Speed | mm/s | 11-22 | 7-15 | 7-15 | 7-18 | 7-18 | 7-12 | 7-12 |
| Return Speed | mm/s | 80 | 90 | 90 | 90 | 90 | 100 | 90 |
| Ejecting Force | kN | 100 | 200 | 200 | 400 | 400 | 630 | 630 |
| Maximum Ejecting Stroke | mm | 160 | 200 | 200 | 200 | 200 | 300 | 300 |
| Name | Unit | YQ32-400 | YQ32-500 | YQ32-630 | YQ32-800 | YQ32-1000 | YQ32-1250 | YQ32-1600 |
|---|---|---|---|---|---|---|---|---|
| Nominal Force | kN | 4000 | 5000 | 6300 | 8000 | 10000 | 12500 | 16000 |
| Maximum System Working Pressure | MPa | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
| Maximum Open Height of Slider | mm | 1250 | 1500 | 1500 | 1500 | 1500 | 1500 | 1500 |
| Maximum Stroke of Slider | mm | 800 | 900 | 900 | 900 | 900 | 900 | 900 |
| Effective Area of Workbench | mm | 1250×1160 | 1400×1400 | 1500×1500 | 1600×1600 | 1600×1600 | 1600×1600 | 1600×1600 |
| Slider Free Fall Speed | mm/s | 100 | 100 | 150 | 100 | 180 | 180 | 190 |
| Pressing Speed | mm/s | 5-11 | 10-18 | 9-18 | 7-18 | 10-18 | 6-15 | 6-14 |
| Return Speed | mm/s | 100 | 180 | 200 | 90 | 220 | 200 | 220 |
| Ejecting Force | kN | 630 | 1000 | 1000 | 400 | 1000 | 1000 | 1600 |
| Maximum Ejecting Stroke | mm | 300 | 300 | 300 | 200 | 300 | 300 | 300 |
Pressing process
Customer Case
