80 tons Forklift Solid Tire Press Machine
The 80-ton forklift solid tire hydraulic press, also known as the 100-ton gantry hydraulic press, adopts a gantry all-steel structure. The machine undergoes vibration aging treatment to minimize mecha
+86 13562463338
+86 13562463338
Video Display
Product Introduction
The 80-ton forklift solid tire hydraulic press, also known as the 100-ton gantry hydraulic press, adopts a gantry all-steel structure. The machine undergoes vibration aging treatment to minimize mechanical deformation.
The frame design is based on finite element analysis, ensuring high rigidity and precision. The gantry-type hydraulic press's working table can move up and down, greatly expanding the machine's opening height and enhancing convenience of use. The 100-ton frame-type hydraulic press consists of components such as the main cylinder, hydraulic power system, and electrical system.
The working table is welded with high-quality steel plates, ensuring reliability and durability. It is widely used in the mechanical industry for disassembly, forming, straightening, aligning, pressing, and sheet metal forming.
It can serve as essential pressure equipment in the modern automotive repair industry. In addition to this, our company also produces 1000-ton frame-type hydraulic presses, 2500-ton frame-type hydraulic presses, etc. We can design and manufacture hydraulic presses of various tonnages according to user parameter requirements.
| Tonnage | Working Pressure | Cylinder Diameter/Rod Diameter | Effective Table Size | Opening Height | Stroke | Pressing Speed | Return Speed | Motor Power | Oil Pump Specification |
|---|---|---|---|---|---|---|---|---|---|
| 100 | 31.5 | D200/d100 | 1000x800 | 1100 | 500 | 7mm/s | 10mm/s | 5.5kw | 10McY (fixed) |
| 120 | 31.5 | D220/d110 | 1000x800 | 1100 | 600 | 6mm/s | 8mm/s | 5.5kw | 10McY (fixed) |
| 160 | 31.5 | D250/d150 | 1400x800 | 1100 | 600 | 6-12mm/s | 15mm/s | 5.5kw | 25McY (fixed) |
| 200 | 31.5 | D290/d160 | 1500x800 | 1200 | 600 | 4-9mm/s | 12mm/s | 5.5kw | 25McY (fixed) |
| 250 | 31.5 | D310/d180 | 1500x800 | 1200 | 600 | 6-12mm/s | 15mm/s | 7.5kw | 40McY (fixed) |
| 300 | 31.5 | D360/d220 | 1500x800 | 1200 | 600 | 4-9mm/s | 15mm/s | 7.5kw | 40McY (fixed) |
| Tonnage | Working Pressure | Cylinder Diameter/Rod Diameter | Effective Table Size | Opening Height | Stroke | Pressing Speed | Return Speed | Motor Power | Oil Pump Specification |
|---|---|---|---|---|---|---|---|---|---|
| 100 | 31.5 | D200/d100 | 1000x800 | 1100 | 500 | 7mm/s | 10mm/s | 5.5kw | 10McY (fixed) |
| 120 | 31.5 | D220/d110 | 1000x800 | 1100 | 600 | 6mm/s | 8mm/s | 5.5kw | 10McY (fixed) |
| 160 | 31.5 | D250/d150 | 1400x800 | 1100 | 600 | 6-12mm/s | 15mm/s | 5.5kw | 25McY (fixed) |
| 200 | 31.5 | D290/d160 | 1500x800 | 1200 | 600 | 4-9mm/s | 12mm/s | 5.5kw | 25McY (fixed) |
| 250 | 31.5 | D310/d180 | 1500x800 | 1200 | 600 | 6-12mm/s | 15mm/s | 7.5kw | 40McY (fixed) |
| 300 | 31.5 | D360/d220 | 1500x800 | 1200 | 600 | 4-9mm/s | 15mm/s | 7.5kw | 40McY (fixed) |
